General Specifications
| IC-F3400 series | IC-F4400series | ||
|---|---|---|---|
| Frequency range (NXDN) (* Depending on version) |
۱۳۶–۱۷۴MHz | ۳۸۰–۴۷۰MHz ۴۵۰–۵۱۲MHz |
|
| Frequency range (dPMR) | ۱۳۶–۱۷۴MHz | ۳۸۰–۴۷۰MHz | |
| Number of channels | ۱۰۲۴ channels /128 zones ۴۰۰۰ channels /128 zones (Option*1 ) ۳۲ channels /2 zones (Non-display type)*2 |
||
| Type of emission (NXDN) (* Depending on version) |
۱۶K0F3E*3 , ۱۴K0F3E, 11K0F3E, 8K50F3E ,8K30F1E/D, 4K00F1E/D | ||
| Type of emission (dPMR) (* Depending on version) |
۱۶K0F3E*3 , ۱۴K0F3E, 8K50F3E, 4K00F1E/D | ||
| Power supply requirement | ۷٫۵V DC nominal | ||
| Current drain (approx.) | Tx (High) | ۱٫۵A | ۱٫۸A |
| Rx (Max./Standby) | ۵۸۰ mA (Internal SP)/140 mA | ||
| Antenna impedance | ۵۰Ω | ||
| Operating temperature range | –۳۰ °C to +60 °C; –۲۲ °F to +140 °F (Radio specifications) |
||
| Dimensions (W×H×D) (Projections not included) |
۵۳٫۶ × ۱۲۳٫۵ × ۲۹٫۳ mm; ۲٫۱ × ۴٫۹ × ۱٫۲ in (with BP-284) |
||
| Weight (approx.) | ۲۱۵ g; 7.6 oz (main unit) | ||
| ۳۴۰ g; 12.0 oz (with BP-284, MB-133 and FA-S81VS) |
۳۳۵ g; 11.8 oz (with BP-284, MB-133 and FA-S81US) |
||
*۱ Optional license key (ISL-CHEX) required.
*۲ IC-F3400D/F4400D/F3400DP/F4400DP (Non-display type): Up to 32 selected channels out of 1024 can be allocated to the channel knob.
*۳ ۲۵ kHz bandwidth is no longer available for FCC Part 90 licensees for USA versions.
DVN: Digital Very Narrow (6.25 kHz), DN: Digital Narrow (12.5 kHz). DN is for NXDN version only.
